Power Magic Ultra Battery (B-124)

For Extended Parking Mode

NEW  12/24V Support

NEW  USB Power Outlet

Fast-Charging. Long-lasting. Expandable.

Power your dashcam in Parking Mode for longer.
Protect your vehicle’s battery. Double your capacity with the optional Expansion Battery.

Free Bluetooth app to visualize battery status.
Full aluminum casing for optimal heat dissipation.

High-Capacity Battery for dashcam Parking Mode

Fast-Charging. Long-Lasting. Connected.

Power Magic Ultra Battery recharges with ignition on and powers your dashcam when ignition is off.

Fast-Charging: the Power Magic Ultra Battery reaches a full charge in a record 40 minutes when hardwired (80 minutes if connected to the cigarette lighter socket).

Long-lasting: Parking Mode can last more than 24 hours with a single-channel BlackVue.

Connected: compatible with the free BlackVue Battery Manager app.

  • Videos
  • Free Download
  • Specifications

Power Magic Ultra Battery

Specifications
Model NamePrivate: Power Magic Ultra Battery (B-124)/ Expansion (B-124E)
Capacity

11 V–14.5 V / 2 A (max)

Product Dimensions

Black / 157 mm (W) x 171 mm (L) x 39.5 mm (H) / 1.4 kg

Operation Temperature

Charging Temperature: 0 °C − 45 °C (32 °F − 113 °F)
Discharging Temperature: -10 °C − 60 °C (14 °F − 140 °F)
Storage Temperature: -10 °C − 35 °C (14 °F − 95 °F)

Storage Temperature

Cigarette lighter plug: 14.6 V / 5 A

Hardwired: 14.6 V / 9 A

High Temp Cut Off

Approx. 80 °C (176 °F)

Backup Battery

Type: LiFePo4

Input Power

Cigarette lighter plug: 12 V–17 V / 6.5 A (max)

Hardwired: 12 V–17 V / 13.5 A (max)

Power Consumption Hour

Cigarette lighter plug (standard 5 A charging): Approx. 80 mins
Hardwired (rapid 9 A charging): Approx. 40 mins
Up to 28 hours (based on a single dashcam that consumes 3 Wh)

Power Magic Expansion Battery

Specifications
Model NamePower Magic Expansion Battery (B-124E)
Capacity

12.8 V / 6,600 mAh / 84.5 Wh

Product Dimensions

Black / 157 mm (W) x 171 mm (L) x 39.5 mm (H) / 1.3 kg

Operation Temperature

Charging Temperature: 0 °C − 45 °C (32 °F − 113 °F)

Discharging Temperature: -10 °C − 60 °C (14 °F − 140 °F)

Storage Temperature: -10 °C − 60 °C (14 °F − 140 °F)

Backup Battery

Type: LiFePo4



Input Power

1 (Ultra) + 1 (Expansion):

§  Cigarette lighter plug (standard 5 A charging): Approx. 1 hour 40 mins in total

§  Hardwired (rapid 9 A charging): Approx. 60 mins in total

Power Consumption Hour

1 (Ultra) + 1 (Expansion):

§  Up to 56 hours in total (based on a single dashcam that consumes 3 Wh)

Expected autonomy in Normal mode*

Model NameAverage power consumption (Wh) in Normal recording modeExpected usage time
DR900S-1CH3.4821h 53m
DR900S-2CH4.5616h 42m
DR750S-1CH3.3622h 40m
DR750S-2CH4.3217h 38m
DR590W-1CH2.5230h 14m
DR590W-2CH3.621h 10m
DR590-1CH2.431h 45m
DR590-2CH3.4821h 53m
*You can take these values as baseline and expect higher autonomy in Parking Mode. Parking Mode autonomy may vary depending on the frequency of motion and impact Event recordings.

Simple or Hardwired installation

For Plug-and-play or professional installation

The Power Magic Ultra Battery supports two charging modes.

Simple installation:
Just plug the battery into the cigarette lighter socket of your vehicle.
Charging current: 5A – Charging time: approx. 80 minutes.

Hardwired installation:
For fastest charging speed, connect the battery to the fuse panel.
Charging current: 9A – Charging time: approx. 40 minutes.

12V/24V COMPATIBILITY, USB POWER OUTPUT

USE IN ANY VEHICLE. CHARGE YOUR ACCESSORIES.

12V/24V compatibility: the Power Magic Ultra Battery (B-124X) supports both 12V and 24V electrical systems. This means it is compatible with most individual and commercial or heavy-duty vehicles on the market.

5V USB (2A max): with its USB power output, you can charge any accessory, such as a phone or a Wi-Fi hotspot to keep your Cloud dashcam connected while in Parking Mode.

BATTERY MANAGER APP SUPPORT

CHECK DETAILED BATTERY INFORMATION FROM YOUR PHONE

Power Magic Ultra Battery supports Bluetooth for compatibility with the free dedicated BlackVue Battery Manager app (iOS/Android).

When charging, the app displays charge percentage, charging voltage and expected remaining time until full charge.

When ignition is off, the app informs you of the expected Parking Mode remaining time until depletion, based on the dashcam’s power consumption.

EXPANSION BATTERY FOR DOUBLE CAPACITY

CONNECT ONE OR MORE EXPANSION BATTERIES

Expansion Battery port: you can connect an Expansion Battery to the Power Magic Ultra Battery to more than double your capacity and Parking Mode time.

The Expansion Battery (B-124E) can store up to 6600mAh of power, so 10% more power than the Ultra Battery.

Multiple Expansion Battery units can be connected in sequence to provide even larger capacity.

POWER YOUR BLACKVUE IN PARKING MODE

With Power Magic Ultra Battery you get amazing autonomy in Parking Mode, without ever drawing power from your car’s battery.
BlackVue dashcams automatically switch to Parking Mode to monitor your parked vehicle, but only writes to the memory card when something happens (motion or impact detected), which has two benefits:

  • Less chance for important files to be overwritten during long Parking Mode sessions.
  • Extended memory card lifespan in the long run.
