Model Name | DR750X-3CH Plus
|
---|
Channel | 3CH
|
---|
Highlights
| Full HD + Full HD + HD (Front + Rear + Interior), Cloud, Wi-Fi, GPS, Dual Sony Sensors, External LTE Module |
---|
Product Dimensions
| Front: Black / W 118.5 mm (4.67″) x H 36 mm (1.42″) / 105 g (3.70 oz)
Rear: Black / W 67.4 mm x H 25 mm / 25 g (0.88 oz)
Interior: Black / W 67.4 mm x H 25 mm / 25 g (0.88 oz) |
---|
Rear Camera Connection
| Coaxial cable
|
---|
Memory Support
| microSD card up to 256GB
|
---|
Recording Modes
| – Normal,
– Event (Impact Detection / Speed Limit / Manual),
– Parking Mode (Impact+Region-based Motion Detection, Timelapse+Events) |
---|
Parking Mode
| YES (with 3-wire hardwiring cable – included) |
---|
Parking Mode Event Voice Notifications
| YES |
---|
Imaging Sensor
| Front: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Rear: Sony STARVIS™ CMOS Sensor (Approx. 2.1 M Pixel)
Interior: Sony CMOS Sensor (Approx.1.27 M Pixel)
|
---|
Viewing Angle
| Front : Diagonal 139°, Horizontal 116°, Vertical 61°
Rear : Diagonal 139°, Horizontal 116°, Vertical 61°
Interior : Diagonal 119°, Horizontal 98°, Vertical 55° |
---|
Resolution Frame Rate
|
Front / Rear / Interior
Full HD (1920×1080) @ 60 fps – Full HD @ 30 fps (1920×1080) – HD (1280×720) @ 30 fps
*Frame rate may vary during Wi-Fi streaming. |
---|
Video Codec
| H.264 (AVC) |
---|
Image Quality and Bitrate Front/Rear
| Front / Rear / Interior
Highest (Extreme): 16 + 10 + 8 Mbps
Highest: 12 + 10 + 8 Mbps
High: 10 + 8 + 6 Mbps
Normal: 8 + 6 + 4 Mbps |
---|
Format Free
| YES (Adaptive) |
---|
Event File Overwrite Protection
| YES (up to 50) |
---|
SD Card Failure Alert
|
YES |
---|
Scheduled Reboot
|
YES |
---|
Video File Extension
| MP4 |
---|
Wi-Fi
| Built-in (802.11 b.g.n) |
---|
Cloud Compatible
| YES |
---|
GPS
| Built-in (Dual Band : GPS, GLONASS) |
---|
Microphone
| Built-in |
---|
Speaker
| Built-in |
---|
Impact Sensor
| 3-Axis Acceleration Sensor |
---|
LED Indicators
| Front: Recording LED, GPS LED, B/W/L LED, Front Security LED
Rear: Rear Security LED
Interior: Interior Security LED |
---|
Rear Camera IR Illumination
| Interior USB: 940 nm (4 Infrared (IR) LEDs) |
---|
Button
|
Button: Wi-Fi ON/OFF (Press)
Proximity sensor: Mic ON/OFF / Trigger Manual Recording / OFF (configurable) |
---|
Operation Temperature
| -20℃ – 80℃ (-4°F – 176°F)
|
---|
Storage Temperature
| -20℃ – 80℃ (-4°F – 176°F)
|
---|
High Temp Cut Off
| Approx. 75℃ (167°F)
|
---|
Backup Battery
| Built-in supercapacitor
|
---|
Input Power
| DC 12V-24V (DC Plug (Ø3.5 x Ø1.1)) to Wires (Black: GND / Yellow: B+ / Red: ACC)
|
---|
Power Consumption Hour
| Normal Mode (Wi-Fi On / GPS On / 3CH) : 540mA / hour
Normal Mode (Wi-Fi Off / GPS On / 3CH) : 510mA / hour
Parking Mode (Wi-Fi On / GPS Off / 3CH) : 495mA / hour
Parking Mode (Wi-Fi Off / GPS Off / 3CH) : 465mA / hour
* Actual power consumption may vary depending on use conditions and environment.
* Approximately, 50mA may increase in electric current when IR LED is turned ON. |
---|
Certifications | Front: FCC, CE, Telec, IC, UKCA, RoHS, WEEE, RCM
Rear: FCC, IC CE, UKCA, RCM, RoHS, WEEE
Interior: FCC, IC, CE, UKCA, RoHS, WEEE
USB Hub: FCC, IC, CE, UKCA, RoHS, WEEE |
---|
software
| BlackVue Viewer
* Windows 7 or higher and Mac OS X Sierra v10.12 or higher |
---|
Application
| BlackVue Application (Android 5.0 or higher, iOS 11.0 or higher)
|
---|
Others
| Adaptive Format-Free File Management System |
---|
Bluetooth | Built-in (V2.1+EDR/4.2)
|
---|
LTE | External (optional)
|
